FlexGuard AX9 TURBO IODigital input/output. list

Terminal lists and jumper settings for FlexGuard AX9 TURBO.

AX9 TURBO

Documentation for:

AX9 TURBO

VikMote AX9 TURBO front view

Controller	Mounting	Supply voltage	Digital inputs	Relay outputs	Analogue inputs	Analogue inputs
Model: AX9 TURBO	Wall mounting	8-36 VDC or 230 VAC	5	4	4	4

Status

AX9 TURBO has been discontinued and can be replaced by NX 910.

Supply voltage

Supply voltage	Terminal	Use	Note
230VAC	P	L1 (100-260VAC / 50/60 Hz)	24 V and 230 V can be connected at the same time
	N	Neutral
		Protective earth
8-36 VDC	DCIN	Plus
8-36 VDC	XGND	Minus

Digital inputs

If digital inputs are used as S0/NPNNPN is a negative signal (minus). then VikMoteController with built-in GSM and data logger. must be supplied with 24 VDC or 230 VAC

Digital inputs	Terminal	Use	Note
Input 1	DI1	If jumper JPDI1 is in position N, the signal on DI1 must be 8-40 VDC (PNPPNP is a positive signal (plus).) If jumper JPDI1 is in position S, the signal must be between GND and DI1 (S0IEC 62053-31 Class A S0 standard for pulse signals./NPNNPN is a negative signal (minus).)	Use PNPPNP is a positive signal (plus). or NPNNPN is a negative signal (minus). signal
Input 2	DI2	If jumper JPDI2 is in position N, the signal on DI2 must be 8-40 VDC (PNPPNP is a positive signal (plus).) If jumper JPDI2 is in position S, the signal must be between GND and DI2 (S0IEC 62053-31 Class A S0 standard for pulse signals./NPNNPN is a negative signal (minus).)
Input 3	DI3	If jumper JPDI3 is in position N, the signal on DI3 must be 8-40 VDC (PNPPNP is a positive signal (plus).) If jumper JPDI3 is in position S, the signal must be between GND and DI3 (S0IEC 62053-31 Class A S0 standard for pulse signals./NPNNPN is a negative signal (minus).)
Input 4	DI4	If jumper JPDI4 is in position N, the signal on DI4 must be 8-40 VDC (PNPPNP is a positive signal (plus).) If jumper JPDI4 is in position S, the signal must be between GND and DI4 (S0IEC 62053-31 Class A S0 standard for pulse signals./NPNNPN is a negative signal (minus).)
Input 5	DI5	The signal on DI5 must be 8-40 VDC (PNPPNP is a positive signal (plus).)	Use only PNPPNP is a positive signal (plus). signal
Ground	GND	Ground for inputs 1..5	Must always be connected

Relay outputs

Relay outputs	Terminal	Use	Note
Output 1	R1A and R1B	Contact set 1, NONormally open.	Max. 5A @ 250VAC / 30 VDC
Output 2	R2A and R2B	Contact set 2, NONormally open.
Output 3	R3A and R3B	Contact set 3, NONormally open.
Output 4	R4A and R4B	Contact set 4, NONormally open.

Analogue inputs

Analogue inputs	Terminal	Use	Note
Input 1	AI1	If jumper JPAI1 is not installed, a 0-10 V signal is used on AI1 If jumper JPAI1 is installed, a 4-20 mA signal is used on AI1	Connect the transmitter between AINx and AGND using 0-10 V or 4-20 mA
Input 2	AI2	If jumper JPAI2 is not installed, a 0-10 V signal is used on AI2 If jumper JPAI2 is installed, a 4-20 mA signal is used on AI2
Input 3	AI3	If jumper JPAI3 is not installed, a 0-10 V signal is used on AI3 If jumper JPAI3 is installed, a 4-20 mA signal is used on AI3
Input 4	AI4	If jumper JPAI1 is not installed, a 0-10 V signal is used on AI4 If jumper JPAI1 is installed, a 4-20 mA signal is used on AI4
Ground	AGND	Ground for analogue inputs	Must always be connected to the transmitter reference point (ground)

Analogue outputs

If analogue outputs are used, VikMoteController with built-in GSM and data logger. must be supplied with 24 VDC or 230 VAC

Analogue outputs	Terminal	Use	Note
Output 1	AO1	If jumper JPAO1 is in position V, a 0-10 V signal is used on AO1 If jumper JPAO1 is in position C, a 4-20 mA signal is used on AO1	Connect the equipment between AONx and AGND using 0-10 V or 4-20 mA
Output 2	AO2	If jumper JPAO2 is in position V, a 0-10 V signal is used on AO2 If jumper JPAO2 is in position C, a 4-20 mA signal is used on AO2
Output 3	AO3	If jumper JPAO3 is in position V, a 0-10 V signal is used on AO3 If jumper JPAO3 is in position C, a 4-20 mA signal is used on AO3
Output 4	AO4	If jumper JPAO4 is in position V, a 0-10 V signal is used on AO4 If jumper JPAO4 is in position C, a 4-20 mA signal is used on AO4
Ground	AGND	Ground for analogue outputs	Must always be connected to the transmitter reference point (ground)

RS485 port 1

RS485 communication	Terminal	Use	Note
Port 1	RS485_1+	RS485 non-inverting signal (A)	Install jumper TER1 to activate a 120 ohm resistor on the bus Read more about termination here
Port 1	RS485_1-	RS485 inverting signal (B)
Ground	SGND	Ground for RS485

RS485 port 2

Note that RS485 port 2 cannot be used at the same time as RS232 port 1

RS485 communication	Terminal	Use	Note
Port 2	RS485_2+	RS485 non-inverting signal (A)	Install jumper TER2 to activate a 120 ohm resistor on the bus Read more about termination here
Port 2	RS485_2-	RS485 inverting signal (B)
Ground	SGND	Ground for RS485

1-Wire

1-Wire communication	Terminal	Use	Note
Port 1	1Wire	1-Wire bus	Connect the equipment between 1Wire and SGND
Port 1	1Wire-LED	1-Wire ID button with LED lamp
Ground	SGND	Ground for 1-Wire

DC outputs

If the 12 V output is used, VikMoteController with built-in GSM and data logger. must be supplied with 24 VDC or 230 VAC
If the 24 V output is used, VikMoteController with built-in GSM and data logger. must be supplied with 230 VAC
Note that DC outputs must be enabled in the program before they can be used

DC outputs	Terminal	Use	Note
DC output 3.3 VDC, max. 300 mA	DCOUT33	Extra 3.3 VDC supply voltage, max. 300 mA	Use jumper JP101 to select between 12 V or 24 V DC output
DC output 12/24 VDC, max. 500/250 mA	DCOUT	Extra 12/24 VDC supply voltage, max. 500 mA at 12 V and max. 250 mA at 24 V
Ground	SGND	Ground for DC
